Fig. 3

Zebrafish hnf-6 expression. (A) Rostral view of 24 hpf embryo showing hnf-6 expression in the retina (large arrow), forebrain (arrowhead), and midbrain (small arrow). (B) Dorsal view of 48 hpf larva showing expression in the liver (arrowhead) and fin buds (arrows). (C) Cross section of 48 hpf larva in the region of the liver showing diffuse low-level expression in the liver (arrowhead) and fin buds (arrow). (D) Dorsal view of 72 hpf larva showing hnf-6 expression in the liver (black arrowhead) and pancreas (white arrowhead). (E) Cross section of 72 hpf larva showing hnf-6 expression in the liver (arrowhead) and hindbrain. (F) Left lateral view of a 5-dpf larva showing hnf-6 expression in the liver (black arrowheads), gallbladder (green arrowhead), and proximal intestine (brown arrowhead).

Expression Data

Gene:	onecut1
Fish:	WT
Anatomical Terms:	forebrain gall bladder gut hindbrain liver midbrain pancreas pectoral fin presumptive neural retina
Stage Range:	Prim-5 to Day 5

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail
