Fig. S7

ID
ZDB-IMAGE-151001-16
Source
Figures for Yang et al., 2015
Figure Caption

Fig. S7

plk2b morphants develop normally without apparent developmental delays. (A-C′′) Fluorescence and bright-field micrographs show that injection of (B–B′′′) plk2b MO1 and (C–C′′′) plk2b MO2 in Tg(kdrl:mcherry-ras) zebrafish embryos results in underdeveloped intersomitic vessel sprouting (open arrowheads), without general morphological abnormalities in whole embryo development at 48 hpf. (A–A′) control MO (n=76/76); (B–B′) plk2b ATG MO (MO1) (n=51/83); (C–C′) plk2b splice MO (MO2) (n=35/87). Scale bar, 500 µm. A′′–A′′′, B′′-B′′′, C′′–C′′′ panels are enlarged images of the boxed area of A–C, A′–C′, respectively. Scale bar, 200 µm. Top, dorsal longitudinal anastomotic vessel (yellow asterisk); bottom, dorsal aorta/cardinal vein.

Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 404(2), Yang, H., Fang, L., Zhan, R., Hegarty, J.M., Ren, J., Hsiai, T.K., Gleeson, J.G., Miller, Y.I., Trejo, J., Chi, N.C., Polo-like kinase 2 regulates angiogenic sprouting and blood vessel development, 49-60, Copyright (2015) with permission from Elsevier. Full text @ Dev. Biol.
