Fig. S3

ID
ZDB-IMAGE-120118-28
Source
Figures for Xu et al., 2012
Figure Caption

Fig. S3 Gβ proteins are expressed during zebrafish embryonic development. (A) Western blot analysis showing the expression of Gβ proteins at 80% epiboly in embryos injected with 4MO (a combination of four MOs that target gnb1a, gnb1b, gnb4a and gnb4b, 4 ng each) was decreased, when compared with that in control uninjected embryos. α-Tubulin was used as a loading control. An anti-pan Gβ antibody (1:5,000, Santa Cruz Biotechnology) and an anti-tubulin antibody (1:10,000, Sigma) were used. (B-E′) Confocal images of wild-type embryos and 4MO-injected embryos immunostained with a pan-Gβ antibody (1:200). Maternally deposited Gβ proteins were present in embryos at the 64-cell and sphere stages (B,C). Expression of Gβ proteins at shield stage and 80% epiboly was not significantly reduced in 4MO-injected embryos (D′,E′). Scale bars: 200 μm in B; 10 μm in C-E2.
