Figure Caption

Fig. S6

Otic neurons (upper panels, in green; pointed to by arrowheads and surrounded by a dotted line in first panel) and anterior macula hair cells (lower panels, in red) in 3 dpf zebrafish larvae in which Gro1 has been knocked-down by morpholinomodified oligonucleotide injection (B, E), or in which the effect of the Gro1 knock-down has been rescued by injection of Gro1 mRNA (C, F). Otic neurons have been detected by anti-HuC immunostaining whereas hair cells of the anterior macula have been detected by anti-HCS-1 immunostaining. Gro1 mRNA has been generated from a Nterminal HA (Hemagglutinin A)-tagged gro1 cDNA, generated by cloning the zebrafish gro1 cDNA in phase into the pCMV-HA vector (Clontech, Mountain View, CA, USA). Adding the HA tag perturbs the integrity of the MO-binding site on gro1 mRNA, preventing binding of the MO. Upper panels are lateral views with a scale bar of 30 μm, lower panels are ventral views with a scale car of 20 μm.

Figure Data
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 357(1), Bricaud, O., and Collazo, A., Balancing cell numbers during organogenesis: Six1a differentially affects neurons and sensory hair cells in the inner ear, 191-201, Copyright (2011) with permission from Elsevier. Full text @ Dev. Biol.
