ZFIN ID: ZDB-IMAGE-110112-45
Figures for Schwend et al., 2010

Figure Caption/Comments:

Fig. S1 Expression of mCherry protein in Tg(Gli-d:mCherry) founder fish. (A–D) Lateral views, anterior to the left, of 24 hpf founder embryos visualized using brightfield (A,B) or fluorescent (C,D) microscopy. mCherry expressing cells could be clearly visualized in the forebrain (arrow in A,B) and myotome (boxed in A,B; see C,D for higher magnification) in some of the embryos injected with the Gli reporter transgene.

Figure Data:
Acknowledgments:
ZFIN wishes to thank the journal for permission to reproduce figures from this article. Please note that this material may be protected by copyright.
