ZFIN Image: Cruz et al., 2010, Fig. S2


Figure Caption

Fig. S2 Eve1 induces meis3 expression via an RA signal. Dorsal views (where discernible) of zebrafish embryos fixed for in situ staining at 70% epiboly. Injections are indicated at the bottom left of each panel (Ctrl, control), and the genes analyzed are indicated at the top right. (A–D) Injection of eve1 mRNA and high concentrations of aldMO (Materials and Methods). Eve1 cannot rescue meis3 expression in aldMO-injected embryos (D). High levels of eve1MO (5 ng/ nL; Materials and Methods) suppresses meis3 expression (E). (F–H) Injection of low concentrations of eve1MO (2 ng/nL) and aldMO indicates synergism between eve1 and aldh1a2 in the regulation of meis3.
