Fig. 4

ID
ZDB-IMAGE-100903-14
Genes
Source
Figures for Noël et al., 2010
Figure Caption

Fig. 4 In situ hybridisation analyses of gc mRNA expression in hdac1 and cloche mutant embryos. Wild type embryos initiate gc expression from 55 hpf, and expression is maintained at 120 and 144 hpf throughout the liver (arrowhead; A and B). gc expression is initiated in the liver in a subset of hdac1 mutants at 120 hpf (arrowhead; C), and all mutant embryos at 144 hpf (arrowhead; D). (E–H) in situ hybridisation combining cp expression (red) and gc expression (blue). At 120 hpf a small subset of cp-positive hepatocytes express gc (arrowhead; F), while at 144 hpf gc is expressed throughout the cp-positive liver (H). Notably, a subset of hdac1 mutant embryos expressing gc in the liver also express gc in the retina (arrow; D). Cloche mutant embryos do not display defects in the initiation of gc expression in the liver at 60 hpf (arrowheads; I, K), or the heightening of gc expression at 72 hpf (arrowheads; J, L). (A–D, I–L) Dorsal views, anterior to the top; (E-H) Lateral views, anterior to the left.

Figure Data
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Gene expression patterns : GEP, 10(6), Noël, E.S., Reis, M.D., Arain, Z., and Ober, E.A., Analysis of the Albumin/alpha-Fetoprotein/Afamin/Group specific component gene family in the context of zebrafish liver differentiation, 237-243, Copyright (2010) with permission from Elsevier. Full text @ Gene Expr. Patterns
