ZFIN Image: Montero-Balaguer et al., 2009, Fig. S3


Figure Caption

Fig. S3 VE-cadherin knockdown does not affect vascular gene expression. In situ hybridization with pan-endothelial (A–B), arterial (C–D), venous markers (E–F) and hematopoietic precursor markers (G–J). Lateral views of the trunk region of 20 hpf embryos are shown, except A, B that report 24 hpf. Embryos injected with high dose (8 ng) of control or VE-cadherin morpholinos (high VEcadMO) were hybridized with the indicated probes (kdrb, dll4, ephB4a, gata1, scl1). High VEcadMO injected embryos (B, D, F, H, J) did not present differences in the expression of these markers when compared to control injected embryos (A, C, E, G).
