Fig. 4

ID

ZDB-IMAGE-260617-10

Genes

EGFP

Antibodies

Publication

Martin et al., 2026 - Nr2f1a and Isl1 repress acquisition of epicardial identity in venous atrial cardiomyocytes

All Figures

Figures for Martin et al., 2026


Figure Caption

Fig. 4 Cells in the venous atria of nr2f1a;isl1 mutants lack Myh6. (A-D″) Optical sections of the venous pole of wild-type, isl1^−/−, nr2f1a^−/− and nr2f1a^−/−;isl1^−/− hearts at 96 hpf stained for Myh6 (blue), Myh7 (red) and fgf13a:EGFP (green). In the schematics, Myh7 (red), Myh6 (blue), Myh6 + Myh7 (orange) and fgf13a:EGFP (green) are shown. Overlap of Myh6 and fgf13a:EGFP in myocardium in A-A″ and C-C″ (white arrows). (D-D″) A fgf13a:EGFP⁺ cell in a gap of Myh6 (yellow arrows), a fgf13a:EGFP⁺ cell on the outside of the atrial myocardial wall (red arrows) and a fgf13a:EGFP⁺/Myh6⁺ cell in the atrial myocardial wall (blue arrows). Scale bar: 10 μm. Wild type (n=9), nr2f1a^−/− (n=11), isl1^−/− (n=4) and nr2f1a^−/−;isl1^−/− (n=13).

Figure Data

Expression / Labeling details
