ZFIN Image: Liang et al., 2025, Fig. 2


Figure Caption

Fig. 2 No iridophores were observed in pnp4a−/− mutants at 4 and 10 dpf. A large number of iridophores were observed on the iris but not on the body surface of wild-type fish (A, B), while no iridophores were observed on the iris and body surface of the pnp4a−/− mutants (C, D) at 4 dpf. Many iridophores were observed on the iris, operculum, peritoneum and swim bladder of wild-type fish (E-G), while no iridophores were observed on the iris, yolk sac and body surface of pnp4a−/− mutants (H-J) at 10 dpf. Compared with the wild type fish, pnp4a−/− mutants displayed black iris (color of RPE) due to the loss of visible iridophores. Blue arrowheads indicate iridophores. Scale bar in A-J, 1 mm.

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from New biotechnology, 89, Liang, G., Lu, B., Dai, S., Li, M., Yao, J., Liu, H., Liu, X., Liu, X., Wang, D., Creation of colorless transparent tilapia using CRISPR/Cas9 mediated multi-gene mutation, 163-176, Copyright (2025) with permission from Elsevier. Full text @ N. Biotechnol.
