Figure Caption

Figure 7

(a) Schematics of the main parts constituting the portable SPIM setup employed in this study. The source beam is expanded by the beam expander (BE) composed of lenses L1 and L2, filtered by the slit and shaped as a light sheet by the cylindrical lens (CL) and the excitation objective (Eobj). The light is collected at a right angle with respect to the excitation by a 4f system composed of the collection microscope objective (Dobj) and the tube lens (TL) and the image is created on a CMOS camera. (b) Schematics of the 3D-printed immersion chamber.
