ZFIN Image: de Sousa et al., 2024, Fig. 2


Figure Caption

Fig. 2

Transmission Electron Microscopy of T. gondii tachyzoites grown in human foreskin fibroblasts. Cells were fixed at 48 h (A, B) and 72 h (C, D) post-infection. Boxed areas in A and C are enlarged in B and D, respectively. T = tachyzoites, n = nucleus, con = conoid, mic = micronemes, rop = rhoptries, dg = dense granules, mito = mitochondrion, rb = residual body; small arrows point towards the parasitophorous vacuole membrane. Bars in (A) = 1.4 μm; (B) = 0.4 μm, (C) = 1.4 μm; (D) = 0.6 μm.
