ZFIN Image: Ruan et al., 2024, Fig 6


Figure Caption

Fig 6 Administration of 17β-estradiol rescued the arrested folliculogenesis of cyp17a1-/-;dmrt1-/- fish.

(A–C) Histological analysis of the ovaries from the control fish, cyp17a1-/-;dmrt1-/- fish, and cyp17a1-/-;dmrt1-/- fish administrated 17β-estradiol from 80 to 110 dpf. (D–F) Anatomical examination of the ovaries from the control fish, cyp17a1-/-;dmrt1-/- fish and cyp17a1-/-;dmrt1-/- fish administrated 17β-estradiol from 80 to 110 dpf. (G) Ratios of PG, PV, EV, MV and FG follicles in fish of each genotype at 110 dpf. PG, primary growth. PV, previtellogenic. EV, early vitellogenic. MV, middle vitellogenic. FG, full grown. Different letters in the bar chart represent significant differences.
