Fig. 1.

ID: ZDB-IMAGE-240129-210
Publication: Nguyen et al., 2023 - TFAP2 paralogs regulate midfacial development in part through a conserved ALX genetic pathway
All Figures: Figures for Nguyen et al., 2023


Figure Caption

Fig. 1.

TFAP2A and TFAP2B cooperatively function in CNCCs during midfacial development. (A-D′) Lateral (A-D) or frontal (A′-D′) views of prenatal mice on embryonic day 18.5 (E18.5). Genotypes are as follows: CTRL (CRE-negative, any Tfap2a/b allelic combination; CRE-positive; Tfap2a^+/flox; Tfap2b^+/flox), Tfap2a^NCKO (CRE-positive; Tfap2a^flox/flox; Tfap2b^+/flox), Tfap2b^NCKO (CRE-positive; Tfap2a^+/flox; Tfap2b^flox/flox) and Tfap2^NCKO (CRE-positive; Tfap2a^flox/flox; Tfap2b^flox/flox). n=5 per genotype. Gold arrowheads in B and C indicate snout indentations. Insets in A′-D′ include higher magnification images of the snout, with misplaced vibrissae outlined. White arrowhead in D indicates the shortened snout; the asterisk indicates mandible hypoplasia. (E) Schematic summarizing regions of Tfap2a and Tfap2b gene deletion in various craniofacial tissues and the corresponding phenotypes (middle, this study; right, Van Otterloo et al., 2018). Regions of deletion are indicated by reduced color intensity.
