Fig. 3.

ID
ZDB-IMAGE-230916-278
Source
Figures for Lim et al., 2023
Figure Caption

Fig. 3.

Effects of parental treatment on zebrafish larvae cortisol stress response. Cortisol levels after a 20 min exposure to (A) combined elevated temperature and hypoxia (offspring combined exposure), (B) a swirling stressor (offspring swirl) or control conditions (offspring control) in 5 days post-fertilization (dpf) larvae derived from adult zebrafish exposed to either control or combined exposure conditions for 14 days. Cortisol levels were compared with two-way ANOVAs followed by post hoc Holm–Šidák tests (A: square-root transformed, parental exposure: P=0.014; larval exposure: P=0.002; parental exposure×larval exposure: P=0.205; B: parental exposure: P=0.973; larval exposure: P<0.001; parental exposure×larval exposure: P=0.374). Differences within treatments across exposure at 5 dpf are indicated by different letters. Differences between treatments for a given exposure at 5 dpf are indicated by an asterisk. Data are means±s.e.m. (all n=6; except combined exposure larvae, swirl, where n=5).

Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image. Full text @ J. Exp. Biol.
