Figure 4—figure supplement 2.

ID: ZDB-IMAGE-190723-1111
Publication: Carretero-Ortega et al., 2019 - GIPC proteins negatively modulate Plexind1 signaling during vascular development
All Figures: Figures for Carretero-Ortega et al., 2019


Figure Caption

Figure 4—figure supplement 2. Angiogenesis deficits of <italic>gipc1<sup>skt1</sup></italic> and <italic>gipc2 <sup>skt3/skt4</sup></italic> mutants at 32 hpf.

(A–C) Confocal lateral images of the trunk vasculature (green) of 32 hpf embryos (region dorsal to the yolk extension). Anterior, left; dorsal, up. Scale bars (white horizontal lines), 100 μm. Genotypes indicated on top of each image in yellow font. Angiogenesis deficits are indicated as follows: white asterisks (DLAV gaps), magenta asterisks (truncated Se), white greater/less-than signs (thin Se). In the WT image (A), the vessels are designated with the white font as follows: DLAV (Dorsal Longitudinal Anastomotic Vessel), Se (Segmental Vessel), DA (Dorsal Aorta), and PCV (Posterior Cardinal Vein). Related to Figure 4.

Figure Data

Phenotype details
