Fig. 4

ID

ZDB-IMAGE-180914-27

Antibodies

Ab1-mt-co1

Publication

Soma et al., 2018 - Elesclomol restores mitochondrial function in genetic models of copper deficiency

All Figures

Figures for Soma et al., 2018


Figure Caption

Fig. 4

ES supplementation rescues pigmentation and the Cox1 deficiency of ctr1-KO zebrafish. (A–C) Clutches of embryos from a WT zebrafish and from a cross of a pair of ctr1^+/− heterozygous zebrafish were imaged at 48 hpf following treatment with and without 10 nM ES. Arrows in B indicate homozygous ctr1^−/− embryos with a pigmentation defect. (D) Mitochondria were isolated from 10-dpf WT zebrafish and homozygous ctr1^−/− zebrafish treated with and without 10 nM ES. Mitochondrial samples were subjected to SDS/PAGE and immunoblotted using the Complex IV-specific antibody anti-Cox1. The mitochondrial protein Atp5a was used as a loading control.

Figure Data

Expression / Labeling details

Phenotype details
