Fig. s7

ID

ZDB-IMAGE-180320-26

Genes

Publication

Kim et al., 2017 - Ottogi Inhibits Wnt/β-catenin Signaling by Regulating Cell Membrane Trafficking of Frizzled8

All Figures

Figures for Kim et al., 2017


Figure Caption

Fig. s7 OTG inhibits reporter expression in TOPdGFP transgenic zebrafish

Views from animal pole, dorsal is to the right. Patterns of GFP reporter expression in control (A, 10/10, 100%), human OTG mRNA-injected (B, 12/13, 92%), zebrafish otg mRNA- injected (C, 12/14, 86%), or otg MO-injected (D, 18/20, 90%) embryo at shield stage (6 hpf). E-H. OTG overexpression suppresses whereas otg knockdown enhances Wnt8-induced reporter expression. TOPdGFP transgenic embryos were injected with indicated combination of wnt8 (7/7, 100%), human OTG (8/10, 80%), zebrafish otg mRNAs (6/10, 60%) and zebrafish otg morpholino (MO, 14/16, 87%). GFP reporter expression is examined by in situ hybridization.

Figure Data

Expression / Labeling details

Phenotype details

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image. Full text @ Sci. Rep.
