ZFIN Image: Pack et al., 1996, Fig. 8


Figure Caption

Fig. 8 Pancreas mutants. Pancreas development in (A,C,E,G) wild type and (B,D,F,H) slj^m74 embryos. (A) Cross-section of the pancreas at 4 dpf showing islet (i) and exocrine (e) cells. (B) In slj^m74 the islet appears normal but the exocrine cells have not developed. (C) Immunoreactive insulin in the wild-type islet. (D) Immunoreactive insulin in the slj^m74 pancreas. (E) Immunoreactive carboxypeptidase A in the wild-type exocrine pancreas. (F) There is little if any immunoreactive carboxypeptidase A in the slj pancreas at 4 dpf. Arrrowheads mark the position of islet cells immunoreactive for insulin. Arrow, background staining in intestine. (G) GATA-5 in situ hybridization in the wild type shows expression in the exocrine pancreas (arrows). (H) slj^m74 does not express GATA-5 in the exocrine pancreas. Scale bars, A,B,D and F, 15 μm; C,E, 20 μm.

Figure Data

Expression / Labeling details

Phenotype details

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image. Full text @ Development
