Fig. 8

ID
ZDB-IMAGE-140113-12
Genes
Publication
de Oliveira-Carlos et al., 2013 - Notch receptor expression in neurogenic regions of the adult zebrafish brain
All Figures
Figures for de Oliveira-Carlos et al., 2013
Figure Caption

Fig. 8 Notch receptor expression in the adult zebrafish hypothalamus.
Notch receptors are differentially expressed throughout the hypothalamus. Cross-sections at the indicated level through the diencephalon. Brightfield images show the expression of A-A′′ , notch1a, B-B. ′′, notch1b and C-C , notch3 at different rostro-caudal levels of the hypothalamus. Strong (filled arrowheads) and weak (unfilled arrowheads) expressing cells are detected. Asterisks () indicate areas of no or very weak expression in the Hd. Abbreviations: DiV, diencephalic ventricle; Hc, periventricular caudal hypothalamus; Hd, periventricular dorsal hypothalamus; Hv, periventricular ventral hypothalamus; LR, lateral recess of the DiV; PR, posterior recess of the DiV; PTN, posterior tuberal nucleus. Scale bar = 100 μm in A (applies to all).

Figure Data
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image. Full text @ PLoS One
