Fig. 5

ID

ZDB-IMAGE-121026-6

Genes

elavl3

Publication

Kok et al., 2012 - Zebrafish rest regulates developmental gene expression but not neurogenesis

All Figures

Figures for Kok et al., 2012


Figure Caption

Fig. 5 Neurogenesis progresses normally in rest mutants. Whole-mount in situ hybridization for the pan-neural marker huC in stage-matched (A,B) 2-somite, (C,D) 8-somite, (E,F) 14-somite and (G,H) 24-hpf wild type or rest heterozygotes and MZrest^sbu29/sbu29 mutants. All views are dorsal, anterior to the left. MZrest mutants did not show ectopic or precocious huC expression. To control for subtle differences in developmental timing and genetic background, comparisons were undertaken in crosses of rest^sbu29/sbu29 females to rest^sbu29/+ males and between wild-type intercrosses and MZrest^sbu29/sbu29 intercrosses. Genotypes were determined by PCR.

Figure Data

Expression / Labeling details

Phenotype details

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image. Full text @ Development
