ZFIN Image: Chong et al., 2012, Fig. 2


Figure Caption

Fig. 2

Developmental phenotype of morpholino-induced knockdown of zSTARS: lateral views of 56 hpf embryos.

A. Embryo injected with control morpholino (with 5 mismatches). The cardiac silhouette is demarcated by arrowheads. The heart tube is looped so that the ventricle (v) and atrium (a) are closely apposed (inset). Circulating red blood cells (rbc) are visible in a thin rim along the inferior aspect of the yolk and within the heart. B. Embryo injected with zSTARS morpholino. The heart tube is unlooped so that the ventricle (v) and atrium (a) are co-linear, with atrial dilation (inset). There is significant edema in the pericardium and over the yolk, with stasis of red blood cells (rbc) over the yolk. C. Lateral view of entire 56 hpf embryo following injection of control, mismatch morpholino. D. and E. 56 hpf embryos showing representative phenotypes of zSTARS morpholino injection.
