Fig. 8

ID
ZDB-IMAGE-111117-29
Genes
Source
Figures for Korzh et al., 2011
Figure Caption

Fig. 8

Defects of swimbladder development in the absence of Fgf10 and Ihha signaling. A–C′, Swimbladder development in control embryos at 50–74 hpf. B′, C′, Anterior chamber (arrowhead) is present at 60, 74 hpf in control larvae. D–F′, Swimbladder development in dae-/- mutant at 50–74 hpf. D, Note phenotype of dae-/- mutant is comparable to control larvae apart from the absence of pectoral fin (arrow). E–F′ Size of swimbladder is reduced in dae-/- mutant compared to control. G–I′, Swimbladder development in ihha-/- mutant. Note that phenotype of ihha-/- mutant is identical to control at each stage, but swimbladder has smaller size that in control and dae-/- mutant. I′, Note that the anterior chamber (arrowhead) is absent in ihha-/- mutants at 74 hpf. K–L′, Swimbladder development in dae-/- embryos injected with Ihha MO. J, Larvae of dae-/- mutant injected with Ihha MO has same size as control. Note the absence of pectoral fin. K–L′, Swimbladder and pneumatic duct epithelia is dramatically reduced in dae-/- mutant injected with Ihha MO at 60–74 hpf. Anterior is to the left. Abbreviations: sb, swimbladder epithelium; pd, pneumatic duct.

Figure Data
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 359(2), Korzh, S., Winata, C.L., Zheng, W., Yang, S., Yin, A., Ingham, P., Korzh, V., and Gong, Z., The interaction of epithelial Ihha and mesenchymal Fgf10 in zebrafish esophageal and swimbladder development, 262-76, Copyright (2011) with permission from Elsevier. Full text @ Dev. Biol.
