Figure Caption

Fig. 1

wdr18 expression pattern during early embryonic development in zebrafish.

(A) wdr18 is maternally expressed. (B) Expression pattern of wdr18 at the 75%-epiboly stage. Black arrow indicates the staining of dorsal forerunner cells (DFCs). (C) wdr18 expression is detected around the Kupffer′s vesicle (white arrowhead) at the 6-somite stage. Inset is an overexposed magnified image showing elevated wdr18 expression around the KV. (D) wdr18 is detected ubiquitously throughout the whole embryo at 18-somite stage. (E) At 3 dpf, wdr18 is expressed in endodermal organs, including the exocrine pancreas (black arrow), liver (white arrow), and intestine.

Figure Data
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image. Full text @ PLoS One
