ZFIN Image: Gerety et al., 2011, Fig. 5


Figure Caption

Fig. 5 Pro-apoptotic Bcl genes puma and bax-a are required for normal boundary marker expression. Embryos injected with either of 2 different puma morpholinos (A–I) or a bax-a morpholino (JvL) show reduction or loss of rfng mRNA expression at the 21ss. Puma knockdown in wild-type (A–C) and tp53 mutant (D–I) embryos showed equivalent reductions in rfng expression (compare B, C and E, F, H, I). A krox20::GAL4 driver line was crossed to a UAS::puma line to force expression of Puma in rhombomeres 3 and 5. Double-positive embryos showed increased apoptosis (data not shown) and ectopic expression of rfng within these 2 segments (compare M and N, O). Similar ectopic rfng expression was detected when this GAL4 line was crossed to a UAS linked auto-activating Caspase3a (Rev-Casp3a, compare N, O and Q, R).

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 350(2), Gerety, S.S., and Wilkinson, D.G., Morpholino artifacts provide pitfalls and reveal a novel role for pro-apoptotic genes in hindbrain boundary development, 279-289, Copyright (2011) with permission from Elsevier. Full text @ Dev. Biol.
