ZFIN Image: Gosse et al., 2009, Fig. 1


Figure Caption

Fig. 1

Morphological and retinotectal phenotypes of radar^s327. (A) Zebrafish radar^s327 mutants have small eyes and appear dark, because of a VBA defect (see text). Dorsal brightfield views of 7 dpf WT sibling and homozygous radar^s327 mutant larvae. (B) radar^s327 mutants lack ventral innervation of the optic tectum. Dorsal confocal projections of 7 dpf larvae show that innervating RGC axons (expressing Brn3c:mGFP) are confined to the dorsal tectum in the mutant. Costaining with a neuropil marker (zrf-3 antibody) reveals that the size of the tectum is similar in WT and mutant. (C) radar^s327 mutants have a compressed dorsal–ventral retinotectal map. Fixed WT and radar^s327 eyes (7 dpf) were injected with DiO (ventrally) and DiI (dorsally). Lateral confocal projections are shown. Arrow highlights ventral tectal region not innervated by RGCs in radar^s327; asterisks show positions of skin melanophores. (Scale bars: 300 μm in A, 100 μm in B and C.)
