Fig. 7 Overexpression of IGF-2a results in abnormal notochord development.
ntl expression in the notochord at the bud stage in a control embryo (panels A and C) and an IGF-2a mRNA injected embryo (panels B and D). ntl expression in the notochord at the 15-somite stage in a control embryo (panel E) and IGF-2a mRNA injected embryos (panels F and G). Among the IGF-2a mRNA injected embryos, 65% showed the expression pattern shown in panel F and 35% showed that in panel G (n = 17). myoD expression in the somite at the bud stage in a control embryo (panel H) and an IGF-2a mRNA injected embryo (panel I). myoD expression in the somite at the 15-somite stage in a control embryo (panel J) and an IGF-2a mRNA injected embryo (panel K). shh expression in the notochord at the 15-somite stage in a control embryo (panel L) and IGF-2a mRNA injected embryos (panels M and N). Among the IGF-2a mRNA injected embryos, 71% showed expression pattern shown in panel M and 24% showed that in panel N (n = 21). myogenin expression in the somite at the 15-somite stage in a control embryo (panel O) and an IGF-2a mRNA injected embryo (panel P). Panels A, B, E–G, and L–N are dorsal view with head up; panels C and D are vegetal view with dorsal the the right; panels H–K, O, and P are dorsal views with head to the left.
