ZFIN Image: Nilsson et al., 2009, Fig. 4


Figure Caption

Fig. 4 Morpholino Knockdown of Candidate Genes in Zebrafish Results in Profound Anemia
WT zebrafish embryos were injected at the one-cell stage with the respective morpholinos and stained at 48 hpf with o-dianisidine to detect hemoglobinized cells.
(A) Uninjected (WT) embryos show normal hemoglobinization as indicated by dark brown staining on the yolk sac (arrow).
(B–G) Morpholino-injected embryos. Accurate morpholino gene targeting was verified by RT-PCR (slc25a39, slc22a4, slc22a5, tmem14c, and c1orf69) or real-time quantitative RT-PCR (isca1) on cDNA from uninjected (WT) or morpholino-injected (mo) embryos. β-actin (actb) was used as a control for off-target effects in the RT-PCR. For RT-PCR, (ctrl) indicates no cDNA template control. For real-time quantitative RT-PCR, (ctrl mo) indicates embryos injected with a standard control morpholino.

Figure Data

Phenotype details

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Cell Metabolism, 10(2), Nilsson, R., Schultz, I.J., Pierce, E.L., Soltis, K.A., Naranuntarat, A., Ward, D.M., Baughman, J.M., Paradkar, P.N., Kingsley, P.D., Culotta, V.C., Kaplan, J., Palis, J., Paw, B.H., and Mootha, V.K., Discovery of genes essential for heme biosynthesis through large-scale gene expression analysis, 119-130, Copyright (2009) with permission from Elsevier. Full text @ Cell Metab.
