Figure Caption
Fig. S7 Expression of ptc1 and ptc2 in wild type and Ihha morphant larvae. (A–B) ptc1 expression was reduced in Ihha-MO larvae as compared to that in control. A notable reduction of expression was observable in the endoderm (white arrows) as well as in the brain region (black arrows). (C–D) Expression of ptc2 was also reduced in morphants as compared to control, although some expression remained in the brain (black arrow) and pharyngeal region (white arrows). Abbreviations: sb, swimbladder. Numbers represent anterior somites. Scale bars: 250 μm.
Figure Data
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and
ZFIN has permission only to display this image to its users.
Additional permissions should be obtained from the applicable author or publisher of the image.
Reprinted from Developmental Biology, 331(2), Winata, C.L., Korzh, S., Kondrychyn, I., Zheng, W., Korzh, V., and Gong, Z., Development of zebrafish swimbladder: the requirement of Hedgehog signaling in specification and organization of the three tissue layers, 222-236, Copyright (2009) with permission from Elsevier. Full text @ Dev. Biol.
