Figure Caption
Fig. S4 Morpholino controls. Live embryos at 1 dpf; genotype is listed in upper right, injected construct is listed in lower right. (A-D) gsc-MO blocks dorsalization by injected gsc, indicating that endogenous gsc is required for dorsalization. (E-G) chd-MO rescued with Xenopus chd RNA. (I-L) Rescue of nog1-MO by nog1 RNA. (M-P) Rescue of fstl1b-MO by fstl1b RNA. (Q-S) Neither low nor high concentrations of standard control morpholino (equivalent to single and triple morpholino experiments, respectively) enhance the chd mutant phenotype.
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and
ZFIN has permission only to display this image to its users.
Additional permissions should be obtained from the applicable author or publisher of the image.
Full text @ Development
