Fig. 3 Gene expression patterns of LMO7 during vertebrate development. Comparison of whole-mount in situ hybridization results of zebrafish, chicken and mouse embryos. Shown are three embryonic stages of each organism in lateral view. A,D,G: Zebrafish embryos are presented at prim-6, long-pec stage, and at 4 days postfertilization (dpf). B,E,H: For chicken, Hamburger-Hamilton stages HH18, HH20, and HH27 are shown. C,F,I: Mouse embryos are presented at 9.5, 10.5, and 11.5 days after gestation. ba, branchial arches; ce, cerebellum; di, diencephalon; fl, forelimb; h, heart; hl, hindlimb; int, intestine; ls, lens; lv, liver; la, liver anlage; lb, lung bud; ma, mandibular arches; mb, midbrain; mes, mesencephalon; met, metencephalon; mhb, midbrain-hindbrain boundary; myel, myelencephalon; ov, otic vesicle; pa, pharyngula arches; pf, pectoral fin buds; som, somites; tct, tectum; tel, telencephalon; tgm, tegmentum.
