Figure Caption
Fig. 1 Transcription of the kal1a and kal1b genes and accumulation of anosmin-1a and anosmin-1b, throughout PLLP migration. In situ detection of kal1a (A–F and J) and kal1b (G–I and K) transcripts in 22 to 38 hpf whole-mount embryos. Magnified views of the primordium at 32 hpf (J and K). The direction of migration is from anterior to posterior. Whole-mount immunodetection of anosmin-1a (L–N) and anosmin-1b (M–O) in 30 hpf embryos. Magnified views of the embryos shown in panels L (N) and M (O). Prim: PLLP; L2: neuromast 2; pL2, pL3: proneuromasts 2 and 3. neu: differentiated neuromasts.
Figure Data
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and
ZFIN has permission only to display this image to its users.
Additional permissions should be obtained from the applicable author or publisher of the image.
Reprinted from Developmental Biology, 320(2), Yanicostas, C., Ernest, S., Dayraud, C., Petit, C., and Soussi-Yanicostas, N., Essential requirement for zebrafish anosmin-1a in the migration of the posterior lateral line primordium, 469-479, Copyright (2008) with permission from Elsevier. Full text @ Dev. Biol.
