ZFIN Image: Gray et al., 2001, Fig. 9


Figure Caption

Fig. 9 Analysis of trunk sensory neurons in des^b420 mutants. Dorsal view (anterior to the left) of a 20-h wild-type (A) and mutant (B) embryo showing islet2 expressing RB neurons. Arrowheads denote the absence of RB neurons in the spinal cord of des^b420 mutants. All three des alleles examined had a similar decrease in RB cells (b420 = 2.5 ± 0.2, b638 = 2.6 ± 0.2, and tp37 = 2.3 ± 0.1 compared to wild type = 3.1 ± 0.2). Lateral view of 72-h wild-type (C) and mutant (D) embryo showing Hu-expressing DRG neurons (arrowheads). (E) islet2-expressing RB neurons and Hu-expressing DRG neurons were counted in hemisegments 5–9; n = 10 embryos for RB counts and n = 6 embryos for DRG counts. See Fig. 7 legend for details regarding statistics. Scale bar, 20 μm.

Figure Data

Phenotype details

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 237(2), Gray, M., Moens, C.B., Amacher, S.L., Eisen, J.S., and Beattie, C.E., Zebrafish deadly seven functions in neurogenesis, 306-323, Copyright (2001) with permission from Elsevier. Full text @ Dev. Biol.
