Fig. 2

ID
ZDB-IMAGE-080410-2
Source
Figures for Liu et al., 2008
Figure Caption

Fig. 2 γ-Tubulin in situ hybridization of 17 α 20 β dihydroxyprogesterone (DHP 1 μg/ml) matured oocytes. γ-Tubulin message was found predominately in the animal pole primordial blastodisc (b). (A, D, G, J and M) incubated with probe; (B, E, H, K, and N) incubated without probe. (M and N) preincubated with RNase prior to hybridization. (G and H) preincubated with demecolcine (1 μg/ml) and DHP prior to fixation and hybridization. J and K preincubated with actinomycin D (1 μg/ml) and DHP prior to fixation and hybridization. (C, F, I, L, and O) are live cells showing primordial blastodisc (b) formation at the animal pole after DHP incubation. (A, B and C) are animal pole views, while all others are side views. Scale bar equals 200 μm.

Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Gene expression patterns : GEP, 8(4), Liu, J., and Lessman, C.A., Changes of gamma-tubulin expression and distribution in the zebrafish (Danio rerio) ovary, oocyte and embryo, 237-247, Copyright (2008) with permission from Elsevier. Full text @ Gene Expr. Patterns
