ZFIN Image: Lachnit et al., 2008, Fig. S4


Figure Caption

Fig. S4 Zygotic Pou5f1 impact on DEL and EVL vegetal closure progression. (A–B) Z-projection of confocal image stacks of a vegetal view of embryos at approximately 90% epiboly stage stained with Sytox green to visualize nuclei. (A) Wild-type (B) Zspg^m793. (C) Measurement of the distance of opposing DEL and EVL margins. DEL cells of Zspg^m793 displayed an average distance of 341 ± 31 μm and those of wild-type siblings 307 ± 31 μm (p < 0.160) The distance of opposing EVL margins was 220 ± 40 μm in wild-type and 217 ± 19 μm in Zspg^m793 (p < 0.951). Embryos resulted from the cross female spg/+x male spg/spg or from the cross female spg/+x male spg/+. The genotypes of embryos were identified after confocal data acquisition by PCR. Scale bar: 100 μm.

Figure Data

Phenotype details

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 315(1), Lachnit, M., Kur, E., and Driever, W., Alterations of the cytoskeleton in all three embryonic lineages contribute to the epiboly defect of Pou5f1/Oct4 deficient MZspg zebrafish embryos, 1-17, Copyright (2008) with permission from Elsevier. Full text @ Dev. Biol.
