ZFIN Image: Bischof et al., 2004, Fig. 6


Figure Caption

Fig. 6 hhex does not repress wnt8 expression at the dorsal margin. (A,B) Whole-mount in situ hybridization for hhex in a cyc^b16 mutant embryo at 50% epiboly. cyc^b16 is a deletion covering the hhex locus, such that mutant embryos lack hhex expression. (C,D) Expression of wnt8 in a wild-type embryo. (E,F) Expression of wnt8 in a representative embryo from a cyc^b16+/- intercross at shield stage: wt, deficiency heterozygous and cyc^b16 mutant embryos have indistinguishable wnt8 expression. (A,C,E: animal view, in C and E dorsal to the right; B,D,F: lateral view, in D and F dorsal to the front; probes used are indicated in the bottom left corner of each panel).

Figure Data

Expression / Labeling details

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 276(2), Bischof, J., and Driever, W., Regulation of hhex expression in the yolk syncytial layer, the potential Nieuwkoop center homolog in zebrafish, 552-562, Copyright (2004) with permission from Elsevier. Full text @ Dev. Biol.
