ZFIN Image: Hamade et al., 2006, Fig. 8


Figure Caption

Fig. 8 Repression and activation, respectively, of fgf8 expression by DEAB and RA. 10-somite stage embryos, oriented as in Fig. 2. (A) fgf8 is expressed in tailbud, anterior psm and anterior aspect of somites; expression in somites decreases as somites maturate. (B) In nls embryos, fgf8 expression is overall reduced. (C) In DEAB-treated embryos, fgf8 is strongly reduced in anterior psm (bracket) and somites. (D) In RA-treated embryos, fgf8 expression is increased in anterior psm (bracket). (E) Blocking of translation by prior incubation in cycloheximide (CHX/RA) does not prevent fgf8 activation by RA in psm (bracket). Scale bar: in panel A, 100 μm for panels A–F.

Figure Data

Expression / Labeling details

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 289(1), Hamade, A., Deries, M., Begemann, G., Bally-Cuif, L., Genet, C., Sabatier, F., Bonnieu, A., and Cousin, X., Retinoic acid activates myogenesis in vivo through Fgf8 signalling, 127-140, Copyright (2006) with permission from Elsevier. Full text @ Dev. Biol.
