ZFIN Image: Hall et al., 2006, Fig. 6


Figure Caption

Fig. 6 Fgfrl1a is essential for chondrogenesis within the ceratobranchial arches. (A/C and B/D) sox9a expression within pharyngeal domain of 60 hpf wildtype and Fgfrl1a morphant larvae, respectively. (A/B and C/D) Lateral views and equivalent sagittal sections, respectively. Asterisk in B marks absence of expression within branchial arches. (E/G and F/H) runx2b expression within pharyngeal region of 54 hpf wildtype and Fgfrl1a morphant larvae, respectively. (E/F and G/H) Lateral and dorsal views, respectively. Abbreviations: B, branchial arches; cb1–5, ceratobranchial arches 1–5; Cl, cleithrum; EP, ethmoid plate; H, hyoid arch; M, mandibular arch. Scale bars: 100 μm in A–H.

Figure Data

Expression / Labeling details

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Mechanisms of Development, 123(12), Hall, C., Flores, M.V., Murison, G., Crosier, K., and Crosier, P., An essential role for zebrafish Fgfrl1 during gill cartilage development, 925-940, Copyright (2006) with permission from Elsevier. Full text @ Mech. Dev.
