Fig. 6

ID

ZDB-IMAGE-070307-35

Genes

Publication

Waxman et al., 2007 - Comparison of the expression patterns of newly identified zebrafish retinoic acid and retinoid X receptors

All Figures

Figures for Waxman et al., 2007


Figure Caption

Fig. 6 Neural expression of zebrafish rxr genes. ISH reveals distinct patterns of rxr gene expression within and near the neural tube. Dorsal views of flatmounted embryos; rxr gene expression is depicted in blue, and krox20, indicating r3 and r5, is shown in red. A: At the 5-somite stage, rxraa is expressed in lateral regions of anterior spinal cord (arrows). B: At the 18-somite stage, rxraa is expressed in the neural crest (arrowheads). C: At the 5-somite stage, rxrga is expressed in the anterior spinal cord. D: At 24 hpf, rxrga is expressed in the anterior spinal cord and the neural crest (arrowheads). E: At the 10-somite stage, rxrgb is expressed in the anterior spinal cord. F: At 24 hpf, rxrgb is expressed at low levels in medial anterior spinal cord. Scale bar = 10 μm.

Figure Data

Expression / Labeling details

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image. Full text @ Dev. Dyn.
