Fig. 5

ID

ZDB-IMAGE-060706-11

Genes

aldh1a2

Publication

Gibert et al., 2006 - Induction and prepatterning of the zebrafish pectoral fin bud requires axial retinoic acid signaling

All Figures

Figures for Gibert et al., 2006


Figure Caption

Fig. 5 Expression of aldh1a2 in wild-type pectoral fins. Whole-mount in situ hybridizations. Anterior is towards the left: dorsal (A) and lateral views (B-F). Pectoral fin buds at 28 hpf (A,B), 32 hpf (C), and 2, 3 and 5 dpf (D-F). (A,B) aldh1a2 is expressed in the posterior part of developing pectoral fins and adjoining lateral plate mesoderm; bracket demarcates the fin proper. (C,D) aldh1a2 expression is restricted to the fin mesenchyme. (E,F) From 3 dpf onwards, expression is restricted to the proximal, anterior and distal margins of the mesenchyme, and is downregulated in the distal margin by 5 dpf. Scale bars: 100 µm.

Figure Data

Expression / Labeling details

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image. Full text @ Development
