FIGURE

Fig. 105

ID: ZDB-FIG-260908-105
Publication: Moens, 2026 - Distinct transcriptional programs define cranial motor neuron subtypes during vertebrate development - ZFIN supplemental image load

Fig. 105

cntn2 HCR (magenta), mnx2b (cyan) and Tg(isl1:GFP-CAAX) (green) at 3 dpf in facial (CN VII) and abducens (CN VI; arrows) motor neurons in hindbrain rhombomeres (r)5 and r6. Mnx2 marks CN VI motor neurons, some of which also express cntn2 at this stage. Cntn2 is also expressed strongly in a subset of CNVII neurons. Single z-section in ventral view with anterior to the top. Ovals: vagus motor neurons (CN X).

Expression Data

Genes:	cntn2 mnx2b
Fish:	fh474Tg (AB)
Anatomical Terms:	rhombomere 5 abducens motor neuron rhombomere 6 abducens motor neuron rhombomere 6 facial motor neuron
Stage:	Protruding-mouth
