Fig. 8

Zglp-1 regulates expression of genes involved in the proliferation and apoptosis of gonadal cells. A, B A comparative analysis was conducted to assess the expression levels of cdc25 and cdca9 genes in wild-type zebrafish versus sf-1^−/− zebrafish at 19 dpf and 35 dpf, respectively. C, D Similarly, the expression of the vasa gene was compared between wild-type and sf-1^−/− zebrafish at both 19 dpf and 35 dpf. E, F Furthermore, the expression of the tp53 gene was evaluated in wild-type and sf-1^−/− zebrafish at 19 dpf and 35 dpf. actb1 was used as a control. Data are presented as mean ± SD. The data were subjected to one-way ANOVA analysis; “ns” indicates the absence of any statistically significant difference, *P < 0.05, **P < 0.01
