Fig 5

ENS neurochemical coding is altered in larval crispants for opioid receptor-encoding genes oprd1b and oprl1.

(A, C, E) Confocal images show whole ENS after immunohistochemistry in 6 dpf control, and oprd1b and oprl1 crispants, respectively. The targeted proteins were Phox2b (yellow), HuC/D (magenta), 5-HT (cyan) and Chat (green). Dashed red lines surround the gut. (B-B””, D-D””, F-F””) depict individual channels and magnification of the ENS midgut region to show the different marker proteins dissected by colors. In parenthesis next to each marker: Cell counts using Imaris software, n = 3 biological replicates.
