FIGURE

Fig. 6

ID

ZDB-FIG-200714-5

Publication

Lechermeier et al., 2020 - Distribution of transcripts of the GFOD gene family members gfod1 and gfod2 in the zebrafish central nervous system

Other Figures

All Figure Page

Back to All Figure Page

Fig. 6

RNA in situ hybridization for gfod1 in adult brain. Pictures show cross sections (80 ?m) arranged from anterior to posterior as indicated in the lateral view scheme. B?-I?, K?-N?, C?, E?, G? and M? are high magnifications of boxed areas in A-I, K?N. Black arrowheads in C? indicate examples of single positive cells in the dorsal telencephalic parenchyme. For abbreviations see abbreviation list (Table 1). Scale bar in A, 100 ?m and pertains to B?N; scale bars in B?-I?, K?-N?, C?, E?, G? and M?, 20 ?m. The scheme is based on Wulliman et al., 1996.

Expression Data

Gene:	gfod1
Fish:	AB
Anatomical Terms:	caudal tuberal nucleus caudal tuberculum cerebellum corpus mamillare diencephalon dorsal periventricular hypothalamus dorsal tegmental nucleus dorsal telencephalon dorsal thalamus fourth ventricle ventral side granular layer corpus cerebelli granular layer valvula cerebelli hypothalamus lateral hypothalamic nucleus medial octavolateralis nucleus medulla oblongata midbrain nucleus Edinger-Westphal nucleus lateralis valvulae olfactory bulb paraventricular organ periventricular grey zone periventricular nucleus periventricular nucleus of caudal tuberculum preglomerular nucleus preoptic area pretectum reticular formation telencephalon torus longitudinalis torus semicircularis ventral telencephalon
Stage:	Adult

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Gene expression patterns : GEP, 36, Lechermeier, C.G., D'Orazio, A., Romanos, M., Lillesaar, C., Drepper, C., Distribution of transcripts of the GFOD gene family members gfod1 and gfod2 in the zebrafish central nervous system, 119111, Copyright (2020) with permission from Elsevier. Full text @ Gene Expr. Patterns
