Fig. 6

A popdc3 knockdown in zebrafish results in a muscular dystrophy phenotype. Healthy control zebrafish embryos display a straight tail (A), whereas a majority of popdc3 morphants display a characteristic curly tail (B). Rhodamine phalloidin whole mount–stained tail of a 3dpf healthy control (C) and popdc3 knockdown (D) zebrafish embryo. The areas demarcated by the white boxes are enlarged in (E) and (F) to highlight the normal myofibrillar structure in most embryos. In comparison to the regular structure of the myotome seen in control embryos (G), some popdc3 morphant embryos (H) display a muscular dystrophy phenotype characterized by areas devoid of myofibers (asterisks), which is probably caused by myofiber rupture (arrows). WT = wild‐type.

Expression Data

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	WT + MO1-popdc3 + MO3-popdc3
Knockdown Reagents:	MO1-popdc3 MO3-popdc3
Observed In:	muscle cell nucleus myotome post-vent region
Stage Range:	Prim-5 to Protruding-mouth
