Fig. 1
- ID
- ZDB-FIG-190605-1
- Publication
- Mishoe et al., 2019 - A frameshift mutation in the PHD Finger Protein 21A repressor of transcription phf21aa
- Other Figures
- All Figure Page
- Back to All Figure Page
Fig. 1
Homozygous 7 dpf mutants have a mild rotation of the ceratohyal cartilage compared to wild-type siblings (indicated by red arrow). Flatmounts of pharyngeal arch 1 and 2 skeleton and neurocranium shows no phenotypic differences in skeletal elements between homozygous wild-type and mutant siblings. Scale bar = 200 microns. Alcian Blue and Alizarin Red staining. |
Expression Data
Expression Detail
Antibody Labeling
Phenotype Data
| Fish: | |
|---|---|
| Observed In: | |
| Stage: | Days 7-13 |
Phenotype Detail
