Fig. 1

col22a1 expression pattern analyzed by WISH. (A-F) col22a1 expression in flat-mounted embryos is viewed in ventral and lateral direction at 29 hpf (A,B), 48 hpf (C,D) and 96 hpf (E,F). The expression was detected in the somitic muscle (arrow, B) and at the myotendinous junction (arrows, D,F). col22a1 expression was also detected around the eyes (asterisks), in the ears, pectoral fins (pf) and pharyngeal arches (arrowheads).

Expression Data

Gene:	col22a1
Fish:	AB
Anatomical Terms:	brain medial region eye anatomical margin eye ventro-medial margin inner ear myotome muscle tendon junction myotome skeletal muscle pectoral fin pharyngeal arch
Stage Range:	Prim-5 to Day 4
