FIGURE

Fig. 5

ID

ZDB-FIG-180608-118

Publication

Eckerle et al., 2017 - Progesterone modulates microtubule dynamics and epiboly progression during zebrafish gastrulation

Other Figures

All Figure Page

Back to All Figure Page

Fig. 5

progesterone and pregnenolone effects on YCL microtubules. (a) Anti-?-tubulin immunostaining of wild-type embryos treated with progesterone or pregnenolone at indicated concentrations, and of ethanol or DMSO treated controls. Scale bar 100 �m. (b) Quantification of progesterone and pregnenolone effects on epiboly progression, measured when control embryos reached 80% epiboly (see also supplemental Fig. S3, a and b). Embryos treated with 75 �M or 100 �M progesterone arrested gastrulation at 30?40% epiboly, marked by stop symbol (50 ? 100 �M: some pregnenolone precipitation occurred). Error bars - SD. (c) Progesterone and pregnenolone measured by ELISA in wild-type embryos incubated in 50 �M progesterone or 20 �M pregnenolone from 2 hpf onward. Pregnenolone levels increase>10-fold, pregnenolone levels>80-fold.

Expression Data

Antibody:	Ab1-tubb
Fish:	AB/TL
Conditions:	chemical treatment by environment: pregnenolone chemical treatment by environment: progesterone
Anatomical Terms:	whole organism microtubule yolk microtubule
Stage Range:	30%-epiboly to 75%-epiboly

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	AB/TL
Condition:	chemical treatment by environment: progesterone
Observed In:	epiboly yolk microtubule yolk microtubule bundle formation yolk microtubule cytoskeleton organization
Stage Range:	30%-epiboly to 75%-epiboly

Phenotype Detail

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 434(2), Eckerle, S., Ringler, M., Lecaudey, V., Nitschke, R., Driever, W., Progesterone modulates microtubule dynamics and epiboly progression during zebrafish gastrulation, 249-266, Copyright (2017) with permission from Elsevier. Full text @ Dev. Biol.
