FIGURE

Fig. S2

ID

ZDB-FIG-170428-21

Publication

Eldred et al., 2017 - Self-organising aggregates of zebrafish retinal cells for investigating mechanisms of neural lamination

Other Figures

All Figure Page

Back to All Figure Page

Fig. S2

R-Cognin is important for embryonic zebrafish retinal cell re-aggregation after dissociation.

24hpf cells after 24 hours in culture (24hic). Cells were treated with either (A) DMSO or (B) 5μM (C) 50μM (D) 100μM or (E) 200μM of PACMA 31, a small molecule inhibitor of R-Cognin. Cells cultured in 5μM PACMA31 (B) generated slightly looser aggregates. Cells cultured with 50μM - 200μM (C-E) PACMA31 were completely unable to aggregate. Scale bar = 50μm.

Expression Data

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image. Full text @ Development
