Fig. 6

Apicobasal polarity is disrupted from the earliest stages of optic vesicle morphogenesis. (A-D) Antibody staining for aPKC in control (A) and lama1^UW1 mutant embryos (B-D) reveals disruption of polarity at 24 hpf. green arrowheads, correct apical domain. yellow arrowheads, ectopic apical domains. asterisks, ectopic puncta. (E-P) Single confocal sections from 4D datasets of apical domain dynamics (marked by pard3-GFP) in a lama1^UW1 control embryo (E-J), or a mutant embryo (K-P). In lama1^UW1 mutant embryos, pard3-GFP localization is disrupted similar to aPKC. dashed blue line marks outline of optic vesicle. green arrowheads, correct apical domain. yellow arrowheads, ectopic apical domains. Dorsal views; scale bar, 50 µm. A, anterior; P, posterior; M, medial; L, lateral.

Expression Data

Antibody:	Ab1-prkcz
Fish:	WT lama1^uw1/uw1
Anatomical Term:	optic cup basal lamina
Stage:	Prim-5

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	lama1^uw1/uw1
Observed In:	establishment of epithelial cell apical/basal polarity involved in camera-type eye morphogenesis optic cup basal lamina
Stage:	Prim-5

Phenotype Detail
